Model:SD0401

Category Brand:
4-50 Ton Hydraulic Press Manual Hand Pump Pressure Gauge Adjustable Bed Shop Tool Industrial Machine for Garage Workshop

Features

  • CE Approved: Ensures safety and compliance for workshop use.
  • 4-50 ton Capacity: Supports heavy vehicle maintenance tasks.
  • Hydraulic Design: Provides smooth and controlled pressure application.
  • Steel Construction: Durable and long-lasting durability.
  • Compact Design: Easy to store and transport.

Specifications

Model Capacity (Ton) Stroke (mm) Total Height (mm) Working Range (mm) Width of Frame (mm) Width of Working (mm) Length of Base (mm) Width of Post (mm) N.W/G.W (kg) Package Packing Size (cm) QTY/20’CY (PCS)
SD0401 4 120 735 340 450 350 405 70 35/37 Carton 58×25×16.5 600
SD0402 10 125 1000 435 545 460 595 100 45/46 Carton 77×35.5×16 550
SD0403 12 125 1470 900 545 460 595 80 49/51 Carton 124×25×16 500
SD0404 20 145 1800 1100 600 500 705 100 87/90 Carton 75×27×19 153×18×15
SD0405 (Double Pump) 20 145 1800 1100 600 500 705 100 87/90 Carton 75×27×19 / 63×19×17 153×18×15
SD0406 (Foot Pump) 20 145 1800 1100 600 500 705 100 87/90 Carton 75×27×19 / 63×19×17 153×18×15
SD0407 30 160 1770 1100 660 495 705 160 130/150 Wooden Box 169×36×21 / 164×21×18 120
SD0408 40 230 1880 1140 805 645 705 170 220/245 Wooden Box 185×95×42 35
SD0409 50 230 1880 1140 805 645 705 170 230/250 Wooden Box 185×95×42 35

Delivery contents

Shipping Information

Accessories

Warranty

We aim to provide the best warranty in the industry, without confusing language. Our goal is for you to feel confident with a simple, reliable warranty.

Please read our warranty policies before ordering, and if anything is unclear, don’t hesitate to ask for clarification. Thank you!

The AnTool LIMITED WARRANTY covers defects in materials, workmanship, and warranted parts. AnTool promises to repair or replace defective parts during the warranty period. Limited warranty does not include labor costs.

Costs incurred for installation, repairs, maintenance and non-warranted parts are the customer’s responsibility.

Wheel Equipment
3 years on major structural components from the date of manufacture
1 years on electric hydraulic power units, pneumatic power units, hydraulic cylinders, cables, hoses, locks, pulleys, sheaves, and bushings
1 year on soft or wear parts (pads, slide blocks, rubber, nylon, neoprene, and optional accessories) from the invoice date
What Is Not Covered or Voids Limited Warranty
